Below is the list of the main sprinklers available in our product range, and are specially developed by us, for various purposes. The main arenas of sprinkler usage however is largely of two types A] Watering, Irrigation and Vegetation B] Ground Wetting to Suppress Dust Pollution.
End Connection : 1/2 " BSP [M]
Application : For Vegetation, Watering And Dust Suppression
MOC : PVC
Water Pressure : 3 kg/sq. cm.
Water Volume : 15 Litres / Minute.
End Connection : 1/2 " BSP [M]
Material : BRASS CASTING
Application : For Dust Suppression and Watering
Volume : 15 Litres / Minute
Water Pressure : 3 kg/sq. cm
End Connection : 3/4 " BSP [M]
Material : BRASS CASTING
Application : For Dust Suppression and Watering
Volume : 48 Litres / Minute
Water Pressure : 4 kg/Sq. cm.
End Connection : 3/4 " BSP [F]
Material : ALUMINIUM CASTING
Application : For Dust Suppression & Watering. This sprinkler has been specially developed for dust zones. Its advantage over other conventional sprinklers are:
A] All casting body, hence less prone to being stolen
B] fully covered spring, bush, washer etc protected from dust and water, hence longer life .
C] Ultra fine particles of water discharged, hence gives proper rain effect and uniform ground wetting.
End Connection : 1 1/2 " BSP [F]
Material : ALUMINIUM CASTING
Application : THERE ARE TWO TYPES OF SPRINKLER IN THIS END CONNECTION. USED MAINLY For Large Area Wetting And Dust Suppression.
Volume : 300 Litres / Minute
Water Pressure : 4.5 - 5 kg/sq. cm.
End Connection : 2" BSP, FLANGE TYPE
Material : C.I. OR ALUMINIUM CASTING
Application : For Very Large Area Wetting [Ash Yard Wetting] and Dust Suppression.
Volume : 450 - 500 Litres / Minute
Water Pressure : 5 - 6 kg/sq. cm.
